升級環境

gcloud composer environments list-upgrades \
  ENVIRONMENT_NAME \
  --location LOCATION

gcloud composer environments list-upgrades example-environment \
  --location us-central1

// GET https://composer.googleapis.com/v1/projects/example-project/
// locations/us-central1/imageVersions

gcloud composer environments check-upgrade \
  ENVIRONMENT_NAME \
  --location LOCATION \
  --airflow-version VERSION

gcloud composer environments check-upgrade example-environment \
  --location us-central1 \
  --airflow-version airflow-2.11.1-build.21

Waiting for [projects/example-project/locations/us-central1/environments/
example-environment] to be checked for PyPI package conflicts when upgrading
to composer-3-airflow-2.11.1-build.21. Operation [projects/example-project/locations/
us-central1/operations/04d0e8b2-...]...done.
...

Response:
'@type': type.googleapis.com/
google.cloud.orchestration.airflow.service.v1.CheckUpgradeResponse
buildLogUri: ...
containsPypiModulesConflict: CONFLICT
pypiConflictBuildLogExtract: |-
The Cloud Build image build failed: Build failed; check build logs for
details. Full log can be found at ...
Error details: tensorboard 2.2.2 has requirement
setuptools>=41.0.0, but you have setuptools 40.3.0.

{
  "imageVersion": "VERSION"
}

gcloud composer environments check-upgrade \
  ENVIRONMENT_NAME \
  --location LOCATION \
  --image-version COMPOSER_3_VERSION

gcloud composer environments check-upgrade example-environment \
  --location us-central1 \
  --image-version composer-3-airflow-2

...
- message: Error validating property [core]unit_test_mode. Overriding [core]
unit_test_mode is not permitted.
type: BLOCKING
- message: Environment variables [GOOGLE_CLOUD_PROJECT] may not be overridden.
type: BLOCKING
- message: You have to specify Worker CPUs to be 0.5, 1.0 or multiples of 2.0.
type: BLOCKING
- message: The environment uses a default maintenance window, which is
different in Composer 2 and Composer 3. Unless set to a custom value, the
maintenance window will be changed to a new default after the upgrade.
type: NON_BLOCKING
...

{
  "imageVersion": "COMPOSER_3_VERSION"
}

gcloud composer environments update \
  ENVIRONMENT_NAME \
  --location LOCATION \
  --airflow-version VERSION

gcloud composer environments update \
  example-environment \
  --location us-central1 \
  --airflow-version airflow-2.11.1-build.21

// PATCH https://composer.googleapis.com/v1/projects/example-project/
// locations/us-central1/environments/example-environment?updateMask=
// config.softwareConfig.imageVersion

  {
    "config": {
      "softwareConfig": {
        "imageVersion": "composer-3-airflow-2.11.1-build.21"
      }
    }
  }

  resource "google_composer_environment" "example" {
  provider = google-beta
  name = "ENVIRONMENT_NAME"
  region = "LOCATION"

  config {
    software_config {
      image_version = "VERSION"
    }
  }
}

resource "google_composer_environment" "example" {
  provider = google-beta
  name = "example-environment"
  region = "us-central1"

  config {
    software_config {
      image_version = "airflow-2.11.1-build.21"
    }
  }
}

gcloud composer operations list \
--locations LOCATION \
--filter='metadata.resource ~ "environments/ENVIRONMENT_NAME$" (metadata.operationType=UPDATE OR metadata.operationType=CREATE)'

┌──────────────────────────────────────┬───────────────┬─────────────┬──────────────────────────────┬───────────┬─────────────────────────────┐
│                 UUID                 │      TYPE     │   LOCATION  │      TARGET_ENVIRONMENT      │   STATE   │         CREATE_TIME         │
├──────────────────────────────────────┼───────────────┼─────────────┼──────────────────────────────┼───────────┼─────────────────────────────┤
│ 71c3d5c9-5b26-4a98-8b19-7f62e9f4ed51 │ UPDATE        │ us-central1 │ example-environment          │ SUCCEEDED │ 2026-10-15T11:18:32.084039Z │
│ 63da3be2-3acf-4fb4-986a-90552a6df8b3 │ UPDATE        │ us-central1 │ example-environment          │ SUCCEEDED │ 2026-08-15T10:56:10.628514Z │
│ 4ebc18a9-25bb-4325-b4c9-0957c67c078b │ UPDATE        │ us-central1 │ example-environment          │ SUCCEEDED │ 2026-06-09T11:30:50.922080Z │
│ 8618f807-abb4-4fc8-9f5b-9353079f6e79 │ UPDATE        │ us-central1 │ example-environment          │ SUCCEEDED │ 2026-05-31T06:57:27.816925Z │
│ 22022864-0fa5-4d1b-92c6-c3f382b43a35 │ UPDATE        │ us-central1 │ example-environment          │ SUCCEEDED │ 2025-11-17T11:52:36.923698Z │
│ ec5bf071-e6c6-4760-b3c9-4a117cb08f7b │ CREATE        │ us-central1 │ example-environment          │ SUCCEEDED │ 2025-11-17T11:17:58.133979Z │
└──────────────────────────────────────┴───────────────┴─────────────┴──────────────────────────────┴───────────┴─────────────────────────────┘

gcloud composer operations describe OPERATION_UUID \
  --location LOCATION \
  --format="value(response.config.softwareConfig.imageVersion)"

gcloud composer environments update \
  ENVIRONMENT_NAME \
  --location LOCATION \
  --airflow-version VERSION

gcloud composer environments update \
  example-environment \
  --location us-central1 \
  --airflow-version airflow-2.11.1-build.21

// PATCH https://composer.googleapis.com/v1/projects/example-project/
// locations/us-central1/environments/example-environment?updateMask=
// config.softwareConfig.imageVersion

  {
    "config": {
      "softwareConfig": {
        "imageVersion": "composer-3-airflow-2.11.1-build.21"
      }
    }
  }

  resource "google_composer_environment" "example" {
  provider = google-beta
  name = "ENVIRONMENT_NAME"
  region = "LOCATION"

  config {
    software_config {
      image_version = "VERSION"
    }
  }
}

resource "google_composer_environment" "example" {
  provider = google-beta
  name = "example-environment"
  region = "us-central1"

  config {
    software_config {
      image_version = "airflow-2.11.1-build.21"
    }
  }
}
