Configure Cloud SQL instance access

This document provides detailed steps for setting up Virtual Private Cloud peering, installing a Cloud SQL proxy, and connecting to an internal Cloud SQL IP address across different Trusted Cloud projects. This setup ensures security-enhanced and efficient communication between your Cloud SQL instance and the following connectors:

• The BigQuery Data Transfer Service MySQL connector
• The BigQuery Data Transfer Service PostgreSQL connector.

This document also covers the creation of a network attachment in the BigQuery Data Transfer Service connector project.

Before you begin

Ensure you have the following:

• Access to a Trusted Cloud project with the BigQuery Data Transfer Service connector and another Trusted Cloud project with the Cloud SQL instance.
• An existing MySQL or PostgreSQL database in a Trusted Cloud project.
• The appropriate permissions to create a VPC, create firewall rules, and install software.
• A virtual machine (VM) instance.

Set up VPC peering

To set up VPC peering, you must create VPC peering from the BigQuery Data Transfer Service connector project, create VPC peering in the Cloud SQL database project to the BigQuery Data Transfer Service project, and configure the routes and firewall rules.

Create VPC peering from the BigQuery Data Transfer Service connector project

1. In the Trusted Cloud console, go to the VPC network peering page for your BigQuery Data Transfer Service connector project.

   Go to VPC Network Peering

2. Click add Create peering connection.

3. In the Name field, enter a name for your peering configuration.

4. For Your VPC network, select the VPC network that you want to peer in the BigQuery Data Transfer Service connector project.

5. For Peered VPC network, select the In another project option.

6. For Project ID, enter the project ID of the Cloud SQL project.

7. For VPC network name, enter the name of the VPC network in the Cloud SQL project.

8. Click Create.

Create VPC peering in the Cloud SQL database project

To create VPC peering in the Cloud SQL database project to the BigQuery Data Transfer Service project, do the following:

1. In the Trusted Cloud console, go to the VPC Network Peering page for your BigQuery Data Transfer Service connector project.

   Go to VPC Network Peering

2. Click add Create peering connection.

3. In the Name field, enter a name for your peering configuration.

4. Select the VPC network that you want to peer in the Cloud SQL database project.

5. For Peer project ID, enter the project ID of the BigQuery Data Transfer Service project.

6. For Peered VPC network, enter the name of the VPC network in the BigQuery Data Transfer Service connector project.

7. Click Create.

Configure routes and firewall rules

If you didn't select import-export routes while configuring the peering connections earlier, follow these steps to do so now:

1. Go to the Routes page for your BigQuery Data Transfer Service connector project.

   Go to Routes

2. Ensure the routes exist to allow traffic between the peered VPC environments.

3. Go to the Firewall policies page.

   Go to Firewall policies

4. Create firewall rules to allow for traffic on the necessary ports (for example, port 3306 for MySQL and port 5432 for PostgreSQL) between the peered networks.

5. Add the custom firewall rules that are required from the BigQuery Data Transfer Service connector project to the Cloud SQL database-hosted project.

6. Configure routes and firewall rules for your project with the Cloud SQL instance as you did in the previous steps.

Set up the Cloud SQL proxy

1. Use SSH to connect to a virtual machine (VM) instance in the BigQuery Data Transfer Service connector project.

2. In the terminal, download the Cloud SQL proxy:

   wget https://dl.google.com/cloudsql/cloud_sql_proxy.linux.amd64 -O cloud_sql_proxy


3. Update the permissions for the downloaded files:

   chmod +x cloud_sql_proxy


4. Run the Cloud SQL proxy:

   ./cloud_sql_proxy -instances=NAME=tcp:3306 or 5432 &


   Replace NAME with the name of your Cloud SQL instance connection.

Connect to the internal Cloud SQL IP address

1. Use the internal IP address of the Cloud SQL instance for connections.
2. Configure your application or tool to connect to the internal IP address, specifying the appropriate credentials and database details.

When connecting from a different Trusted Cloud project, use the internal IP address of the proxy VM that you deployed earlier. This solution resolves transitive peering issues.

Create the network attachment

To create the network attachment in the BigQuery Data Transfer Service connector project, follow these steps:

1. In the Trusted Cloud console, go to the Network attachments page.

   Go to Network attachments

2. Click add Create network attachment.

3. Provide a name for the network attachment.

4. Select the appropriate VPC network.

5. For Region, specify the region where your BigQuery Data Transfer Service connector is located.

6. For Subnetwork, select the appropriate option that matches your setup.

7. Click Create network attachment.

Test the connection

1. Verify that the VM with the Cloud SQL proxy can connect to the Cloud SQL instance:

   mysql -u USERNAME -p -h IP_ADDRESS


   Replace the following:

   • USERNAME: the username of the database user
   • IP_ADDRESS: the IP address of the Cloud SQL instance

2. Ensure that applications in the BigQuery Data Transfer Service connector project can connect to the Cloud SQL instance using the internal IP.

Troubleshoot

If you are having issues setting up your network configuration, do the following:

• Ensure that VPC peering is established and that routes are correctly configured.
• Verify that the firewall rules allow for traffic on the required ports.
• Check the Cloud SQL proxy logs for errors and ensure it is running correctly.
• Ensure that the network attachment is correctly configured and connected.
